This 28'x40' modern cabin floor plan delivers 1,296 sq ft of living space across a ground floor and a fully developed loft, with a steep 10:12 gable roofline and dramatic exposed timber trusses visible from both the south elevation and the interior. The ground floor centers on an open-concept living and kitchen area, two bedrooms, a full bath, a mudroom with direct entry, and a covered front porch and rear porch that wrap the home in outdoor living space. The loft level adds a third bedroom, a second full bath, a reading area, and open loft living that takes full advantage of the vaulted gable ceiling.
Construction is wood frame with 2x6 exterior studs, board-and-batten vertical siding, a steep gable roof with exposed timber truss detailing, and a concrete slab with pier footing foundation. The 28-foot width keeps the footprint manageable for narrow or wooded lots, while the loft configuration maximizes livable square footage without adding a full second story. The 17-sheet plan set includes floor plans for both levels, foundation plan and slab, wall layout, ceiling and roof framing, all four elevations, two sections, electrical and plumbing plans, kitchen and bathroom details, door and window schedules, join details, and a full material list.
Whether you are planning a primary residence, a vacation retreat, a short-term rental, or an owner-built cabin on a rural lot, this complete drawing set gives you everything needed to begin construction. Available as an instant PDF and CAD download. Note that Home Plan DIY does not provide engineer-stamped plans; buyers should verify local code and engineering requirements before construction.
