Plan C-25-111: 28'x22' Modern Cabin House Plan 1BR/1BA, 602 sq ft

Name: Plan C-25-111: 28'x22' Modern Cabin House Plan 1BR/1BA, 602 sq ft
Brand: Home Plan DIY
SKU: 25111
Price: 449.0 USD
Availability: InStock

$449.00

PDF + CAD/DWG + RVT + SKP · All formats included

Instant Download

Full Plan Set

Customisation

Live Help

Secure Checkout & Instant Download

Compact 602 sq ft modern cabin floor plan with open living and dining, full kitchen, laundry, WIC, and a 28-ft front porch. PDF and CAD download.

About This Plan

This 28'x22' modern cabin floor plan delivers 602 sq ft of efficiently arranged single-story living space with a clean contemporary profile and a full-width front porch spanning the entire 28-foot facade. The open-concept living and dining area measures 17'9"x9'9" and flows directly into the kitchen at 11'2"x4'9", creating a bright, connected main living space. A private bedroom with a walk-in closet, a full bathroom, and a dedicated laundry area with washer and dryer connections round out a layout that maximizes every square foot without feeling cramped.

The home is built on a concrete pier foundation with 2x6 wood framing, black corrugated metal roofing, and cedar tongue and groove ceiling details that give the interior a warm, crafted finish. The gable roof with shed porch overhang creates a distinctive modern cabin aesthetic suited to wooded lots, hillside sites, and off-grid builds. The single-story layout keeps construction costs manageable and makes the home accessible for a wide range of owner-builders.

Whether you are planning a primary residence, a vacation cabin, a short-term rental, or an accessory dwelling unit, this complete 22-sheet drawing set gives you everything needed to begin construction. Sheets cover the floor plan, slab layout, ceiling and roof outline, all four elevations, two sections, electrical and plumbing plans, kitchen and bath details, rafter and framing details, insulation details, window and door schedules, and a full material list. Available as an instant PDF and CAD download. Please note that Home Plan DIY does not provide engineer-stamped plans. Buyers should verify local engineering and code compliance requirements before construction, as some jurisdictions require a licensed architect or engineer to review and seal plans prior to permitting.

Details

Heated SQ FT

Total Heated Area 602 sq ft

First Floor 602 sq ft

Porch & Patio SQ FT

Total Porch/Patio Area 168 sq ft

Front Porch 28'x6'

Bedrooms 1

Full Baths 1

Width 28 ft

Depth 21 ft 6 in

Height 18 ft

Exterior Framing 2x6

Ceiling Heights

First Floor 9 ft 6 in

What's Included in These Plans?

Complete Architectural Floor Plans
Loft & Open Living Space Layouts
Roof, Ceiling & Building Section Drawings
Exterior Elevations from All Sides
Kitchen & Bathroom Construction Details
Door, Window & Opening Schedules
Electrical & Plumbing Layout Plans
Wall, Rafter & Foundation Details
Material List for Construction Planning
Builder-Ready House Blueprints in PDF Format

What's Not Included

Site work, Landscaping, Permits, Utility connections, Appliances, Furniture . Some jurisdictions require a local engineer to review and stamp the plans. Check with your local building department before construction. . Some jurisdictions require a local engineer to review and stamp the plans. Check with your local building department before construction.

Estimated Build Cost

Range

$78,260 to $132,440

Per sq ft

$130 to $220

Final costs may vary significantly based on local market conditions, foundation requirements, utility connections, permits, and customization options. For the most accurate pricing, we recommend sharing the included plans and material list with local contractors or builders for detailed quotations.
