Plan C-25-147: 20'x50' Modern Cabin Plan 2BR/2BA with Loft, 1,430 sq ft

Name: Plan C-25-147: 20'x50' Modern Cabin Plan 2BR/2BA with Loft, 1,430 sq ft
Brand: Home Plan DIY
SKU: 25147
Price: 449.0 USD
Availability: InStock

$449.00

PDF + CAD/DWG + RVT + SKP · All formats included

Instant Download

Full Plan Set

Customisation

Live Help

Secure Checkout & Instant Download

Narrow 1,430 sq ft modern cabin with loft bedroom, 2 full baths, open dining and living, full kitchen, laundry, utility room, and clearstory roof. PDF and CAD.

About This Plan

This 20'x50' modern cabin floor plan delivers 1,430 sq ft of heated living space across a well-organized main floor and a loft, designed for narrow lots, wooded sites, and elevated or sloped terrain where a compact footprint is an advantage. The main floor layout includes a combined dining and living area, a full kitchen at 12'8"x9'11", a private bedroom with closet, a full bathroom with shower, a laundry area, a utility room with furnace, and cabinet storage. A stair leads to the loft level, which includes a second bedroom at 11'7"x11'11", two closets, and a second full bath, making the loft fully functional as a private bedroom suite. Two storage rooms flanking the loft stairwell add practical utility for gear, tools, or seasonal items.

The steep gable roofline with clearstory windows rising to 16 ft 11 in gives this narrow plan a striking vertical profile and brings elevated natural light deep into both living levels. Built on a concrete pier foundation with 2x4 wood framing, corrugated metal roofing, and cedar tongue and groove ceiling details, this home is designed for durability and low maintenance. The narrow 20-foot width makes it one of the most site-flexible plans in the lineup, fitting lots where wider designs cannot.

Whether you are planning a vacation cabin, a short-term rental, or a full-time residence on a narrow or challenging lot, this complete 23-sheet drawing set gives you everything needed to begin construction. Sheets cover the ground floor and loft plans, slab layout, ceiling and roof outline, all four elevations, two sections, electrical and plumbing plans, kitchen and bath details, rafter and framing details, insulation details, window and door schedule, and a full material list. Available as an instant PDF and CAD download. Please note that Home Plan DIY does not provide engineer-stamped plans. Buyers should verify local engineering and code compliance requirements before construction, as some jurisdictions require a licensed architect or engineer to review and seal plans prior to permitting.

Details

Heated SQ FT

Total Heated Area 1430 sq ft

First Floor 1,000 sq ft

Second Floor 430 sq ft

Bedrooms 2

Full Baths 2

Half Baths 0

Floors 1.5

Width 20 ft

Depth 50 ft

Height 22 ft 6 in

Exterior Framing 2x4

Ceiling Heights

First Floor 8 ft

Second Floor 10 ft 11 in

What's Included in These Plans?

Complete Architectural Floor Plans
Loft & Open Living Space Layouts
Roof, Ceiling & Building Section Drawings
Exterior Elevations from All Sides
Kitchen & Bathroom Construction Details
Door, Window & Opening Schedules
Electrical & Plumbing Layout Plans
Wall, Rafter & Foundation Details
Material List for Construction Planning
Builder-Ready House Blueprints in PDF Format

What's Not Included

Site work, Landscaping, Permits, Utility connections, Appliances, Furniture . Some jurisdictions require a local engineer to review and stamp the plans. Check with your local building department before construction. . Some jurisdictions require a local engineer to review and stamp the plans. Check with your local building department before construction.

Estimated Build Cost

Range

$185,900 to $314,600

Per sq ft

$130 to $220

Final costs may vary significantly based on local market conditions, foundation requirements, utility connections, permits, and customization options. For the most accurate pricing, we recommend sharing the included plans and material list with local contractors or builders for detailed quotations.
