This 36'x28' modern house floor plan delivers 1,008 sq ft of open, single-floor living in a layout that makes the most of every square foot. The interior centers on a generous open living area with a fireplace, a kitchen with island and pantry, and a dining space, all flowing together under 11 ft 6 in ceilings. Two private bedrooms each have dedicated closets and share a full bathroom, with a laundry and utility room tucked nearby. A covered rear patio spanning 248 sq ft extends the living space outdoors and adds a protected outdoor area accessible directly from the main living zone.
Built on a concrete slab foundation with wood framing, insulated walls, and energy-efficient windows, this home is designed for year-round comfort in a wide range of climates. The 9:12 gable roof reaches 24 ft 6 in and gives the structure a bold, angular profile with strong vertical presence. The lower 2:12 shed roof over the rear patio ties the indoor and outdoor spaces together visually while providing covered protection from rain and sun.
Whether you are planning a primary residence, a vacation rental, a lakeside getaway, or a compact family home, this complete 17-sheet drawing set gives you everything needed to begin construction. Sheets cover the floor plan, foundation plan and slab, wall layout, ceiling and roof framing, all four elevations, two sections, electrical and plumbing plans, kitchen and bath details, door and window schedule, joint details, and a full material list. Available as an instant PDF and CAD download. Please note that Home Plan DIY does not provide engineer-stamped plans. Buyers are responsible for verifying local engineering and code compliance. Some jurisdictions require a licensed architect or engineer to review and seal plans before construction.
